by MIMECO
H8071 General Purpose Relay 24VAC 5A 8 Pins
SKU 1YCN6
Original price
$19.80
-
Original price
$19.80
Original price
$19.80
$19.80
-
$19.80
Current price
$19.80
H8071 General Purpose Relay Base Shape Square Coil Voltage 24V AC Contact Form DPDT Current Rating 5 A Electrical Connection Quick-Connect Flat Pin Width 0.187 in Number of Pins 8 Pin Shape Flat Sealing Enclosed Status Indicator LED Indicator Mechanical Flag Contact Rating (AC) 2 A @ 250V 5 A @ 250V Contact Rating (DC) 3 A @ 30V 5 A @ 30V Horsepower @ 120V AC 1/6 hp Horsepower @ 240V AC 1/3 hp Mounting Style Plug-In Push-To-Test Method Manual Body Depth 1.4 in Body Height 1.14 in
Standard shipping
Estimated delivery time: 7-10 days
Specifications
